| ENGINE |
Type |
471 cc, Water Cooled, 4-stroke, 1-cylinder |
Bore x Stroke |
3.33” x 3.30” |
Compression Ratio |
9.4：1 |
Max. power |
20HP/5500rpm |
Max. torque |
27.00N.m/5000-5500rpm |
Carburetion |
PD33J-A |
Ignition |
CDI |
Start type |
Electric/Pull start |
Transmission |
L-H-N-R-P |
Drive Train |
Shaft Drive |
|
| CHASSIS |
| Suspension/Front |
Independent double swing arm |
| Suspension/Rear |
Independent double swing arm |
| Brakes/Front |
Dual ventilated hydraulic disc |
| Brakes/Rear |
Ventilated hydraulic disc |
| Tires/Front |
AT25×8-12 radial |
| Tires/Rear |
AT25×10-12 radial |
|
| DIMENSIONS |
| Product Dimension |
L x W x H： 87”x51”x50” |
| Seat Height |
34” |
| Wheelbase |
54” |
| Ground Clearance |
10” |
| Fuel Capability |
4.5Gal/17L |
| Dry Weight |
683 lbs |
| Battery |
12V/21Ah |
| Gross/Net Weight (lbs) |
926/703 lbs |
| Lighting/Front |
12V35W/35Wx2, 12V5Wx2 |
| Lighting/Rear |
12V5W/21Wx1 |
| Loading QTY(20FT/40FT/40HQ) |
8/18/27 |
|
